Model |
unit |
YTDC-250 |
YTDC-320 |
YTDC-400 |
YTDC-500 |
| Minimum Index |
|
Standard 5° Special 1° |
| Table Diameter |
mm |
Φ
250 |
Φ
320 |
Φ
400 |
Φ
500 |
| Horizontal Position Height |
mm |
200 |
240 |
265 |
300 |
|
Center Height of
Vertical Position |
mm |
170 |
230 |
250 |
310 |
| Table Center Hole Diameter |
mm |
Φ55H7 |
Φ100H7 |
Φ120H7 |
Φ120H7 |
|
Table Center
Hole Diameter |
mm |
Φ
30 |
Φ
80 |
Φ
80 |
Φ
90 |
|
Table T-Slot
Width |
mm |
12H7 |
14H7 |
14H7 |
18H7 |
|
Standard guide
block Width |
mm |
18H7 |
18H7 |
18H7 |
18H7 |
|
Servo Motor
(FANUC series) |
|
HA-80C-S |
HA-100C-S |
HA-100C-S |
HA-100C-S |
|
Servo Motor
(MITSUBISHI series) |
|
α
6 |
α
12 |
α
12 |
α
12 |
|
Gear Ratio |
|
1/120 |
1/72 |
1/120 |
1/180 |
Total speed
(Motor 2000rpm)
Rotation Speed |
r.p.m |
16.6 |
27.7 |
16.6 |
11.1 |
|
Clamping force |
kgf-m |
300 |
400 |
500 |
600 |
|
Vertical Load
Capacity |
kg |
300 |
350 |
500 |
600 |
|
Horizontal Load
Capacity |
kg |
125 |
175 |
250 |
300 |
|
Clamping Torque
force |
kgf-m |
250 |
350 |
450 |
550 |
|
Indexing
Accuracy |
sec |
±
4" |
±
4" |
± 4" |
±
4" |
|
Net Weight |
kg |
110 |
220 |
300 |
450 |
